3D GEL Number 8 Digits

3D GEL Number 8 Digits

3D GEL Number 8 Digits

£11.00

In stock

£11.00

This pack of 10 3D GEL Number 8 Digits in the Charles Wright font are certified to make BSAU145e Number Plates.

SKU: nc0628 Category:

Description

  • Pack Contents: 10 x Number 8
  • Type: 3D GEL Digits
  • Size: 79x50x2mm
  • Colour: Solid Black
  • Material: Polyurethane Resin
  • Compliance: BSAU145e
  • Features: High-Tack Adhesive with Backing Paper.

Our 3D GEL Number 8 Digits are fabricated using a long-lasting resin and the Charles Wright Font. After curing, the black polyurethane resin provides the slick, gel-like signature finish to each digit. GEL digits create upsell & customisation opportunities for retailers, motor factors & part-stores.

Tennants 3D GEL Number Plates are BSAU145e Certified by an Independent UKAS Testing Laboratory, just like our True 3D Digit plates. Setting a new benchmark for GEL digit quality, readability and compliance in the UK Market. But this is subject to the correct use of digits on specific constructions, like Film, Reflective or 3-Part Plates. Only then, can we guarantee your number plates are road legal and standards compliant.

BSAU145e Compliant GEL Number Plates

This is a quick guide to making a 3D GEL Number Plate using our stick-on digits. For a more detailed guide check out the GEL Assembly Guide on the NP Knowledge Base on our main website.

Tennants 3D GEL Number Plates

3D GEL Assembly Guide

To start, simply make your number plate as normal. Ensure you remove the protective cover from the acrylic face. And always bond your components together using a jig and roller. Follow each step and your plate will be done in no time.

1: Setup and Prepare the Number Plate

Prepare Your GEL Number Plate

Place your number plate flat on a clean and well lit work-surface or use your Jig. Or set up & configure your stencil mount for the number plate size & format used.

2: Select & Prepare a GEL Digit

Select & Prepare a GEL Digit

Remove the paper backing from the rear of the first digit. This side has the high-tack adhesive and is completely flat without bevelled edges.

3: Position the Digit in Place

Position the GEL Digit in Place

Using your Stencil Mount or the Registration as a guide, get a digit into place. Since it uses the same font, a printed registration is a perfect alignment guide.

4: Push the Digit Down Firmly

Push the Digit Down Firmly

Press the digit down firmly into place. Hold it on the surface for a few seconds, so the high-tack adhesive can bond. Now repeat these steps for each character.

Note: Wait a few minutes after mounting for the glue to start curing before handling.

5: Clean & Buff Number Plate

Finally Clean and Buff the Number Plate

Get you number plate ready for your customer by buffing it with cleanser and a micro-cloth. Gently buff away any fingerprints or left-over residue.

Additional information

Dimensions79 × 50 × 2 mm
3D Digits

3D Gel, Gel Numbers

Digit Size

79mm Digits

Product Brand

Tennants UK
