10 Yellow 2-Part Oblong Plates
This bundle of matched components produces 10 Yellow 2-Part Oblong Plates compliant with BSAU145d.
Includes: 10 x nrd001y + 10 x nas000
- Additional information
This bundle of 10 Yellow 2-Part Oblong Plates has been created to encourage compliant number plate production. Our British Standard certification is for finished number plates made with this specific plate media. So we can guarantee number plates made from them will be road legal, subject to correct use.
- SKU/Part No: 10tuk001y
- Plate Size: Standard Oblong 520x111mm
- Plate Colour: Yellow
- Bundle Includes: 10 Yellow Oblong Dry Reflective Sheets (nrd001y) and 10 Oblong Acrylic Faces (nas000)
As can be seen from the contents, you have to print and join our components together to make number plates. Therefore ensure your system prints onto reflective before buying this 10 Yellow 2-Part Oblong Plates bundle. Just like our thermal number plate printing solution for dealerships and service centres.
10 x Yellow Oblong Dry Reflective Sheets – nrd001y
Oralite Number Plate Reflective is designed for printed number plate production. For 2-part number plates, you simply print on and then laminate it to the back of an acrylic face. Each retro reflective sheet is fade resistant and coated to help prints bond to the surface.
Standard 2-Part Number Plates
Tennants standard number plates realise the full potential of the basic printed number plate. And yet with just two components, we created a combination that satisfies all standards and regulations. But also keeps costs low and simplifies the assembly process.
BSAU145d Number Plates
Making number plates is easy with our 3 step process.
1: Design 2: Print 3: Assemble
First, you design a number plate in our compliant software. Second you print it onto our plate media. And finally, assemble the specific matched components together.
But only when you use each part of our combined solutions, can we guarantee your number plates will be 100% legal.
Assemble with a Jig & Roller
When laminating your plate media together, we recommend using a jig and roller or a professional finish.
- Use the pins and place your printed Reflective on the jig, positioned flat and square.
- Fold back a few centimetres of the adhesive cover on an Acrylic Face.
- Line up the Acrylic on top, Adhesive facing down towards the reflective.
- Carefully join the components together at the Exposed adhesive, ensure the edges match.
- Slide both parts towards the rollers, with the Joined edge nearest.
- Take and keep Hold of the folded adhesive cover.
- Slowly Wind the arm so the components are fed through the roller.
- The adhesive cover should be Removed while the roller bonds the parts together.
- Finally, remove the other Protective Cover from the Acrylic.
|Dimensions||520 × 111 mm|
