11×8 Reflective Bundles

11x8 Reflective Bundles

11×8 Reflective Bundles

£87.00£217.50

In stock

£87.00£217.50

Our 11×8 Reflective Bundles include Clear Acrylic & Dry Reflective for making BSAU145e Number Plates.

Bundle: Choose a 20 or 50 Plate Bundle.

SKU: N/A Category:
Clear

Description

Our 11×8 Reflective Bundles includes Clear Acrylic Faces & Yellow Dry Reflective Sheets. No matter which bundle size you choose, it’s matched components are covered by our BSAU145e certification shown on our website. So we guarantee your number plates will be road legal, subject to correct use. And this size makes 2-line number plates for the rear of 4×4 vehicles

  • Size: 11×8 inch or 280x203mm
  • Contents: Clear Acrylic & Dry Reflective
  • Bundle Size: 20 or 50 Plates
  • Colour: Yellow Only
  • For: Square 4×4 Number Plates
  • Discount: 10% Off Trade Rate*

As you know, you have to print and join our components together to make a number plate. Therefore ensure your system prints onto reflective sheets before buying this matched bundle.

Note* Reduction applies to standard trade accounts only. Customers with discount rates get their pre-agreed discount.

Bundle Components

11x8in Clear Acrylic

naw002 - 11x8in Clear Acrylic Face

All our Clear Acrylic Faces are certified to make Tennants number plates. But only when laminated to specific number plate components. Every clear acrylic face is UV stable to resist discolouring and comes with a wet adhesive for easy assembly.

11x8in Dry Reflective – Yellow

nrd002y - Yellow 11x8in Dry Reflective Sheet
Oralite Number Plate Reflective is designed for printed number plate production. For Reflective Number Plates, you simply print on and then laminate it to the back of an acrylic face. Each retro reflective sheet is fade resistant and coated to help prints bond to the surface.

Reflective Number Plates

Reflective & Acrylic Construction

Make a reflective number plate by laminating your Printed Dry Reflective underneath an Acrylic Face.

For more information on standards and regulations, check out our main site and the number plates pages or knowledge base.

Combining Matched Components

Jig combining reflective and acrylic

Make a number plate using our 3 step process.
1: Design 2: Print 3: Assemble
Build it in our software, then print it out and simply assemble the matched components together.

Assembly with a Jig & Roller

Whenever you make a printed number plate, we recommend using a jig and roller for a professional finish.

Reflective Plates
  • Use the pins and place your Reflective on the jig, positioned flat and square.
  • Fold back a few centimetres of the adhesive cover on an Acrylic face.
  • Line up the Acrylic on top, Adhesive facing down towards the reflective.
  • Carefully join the components together at the Exposed adhesive, ensure the edges match.
  • Slide both parts towards the rollers, Joined edge nearest.
  • Take and keep Hold of the folded adhesive cover.
  • Slowly Wind the arm so the components are fed through the roller.
  • The adhesive cover should be Removed while the roller bonds the parts together.
  • Finally, remove the other protective Cover from the Acrylic.

Additional information

Dimensions280 × 203 mm
Media Type

Reflective Plates, Matched Bundles

Product Brand

Tennants UK
