9×7 3-Part Bundles

9x7 3-Part Bundles

9×7 3-Part Bundles


In stock


Our 9×7 3-Part Bundles include Clear Acrylic, Clear Film & Wet Reflective for making BSAU145e Number Plates.

Bundle: Choose a 20 or 50 Plate Bundle.

SKU: N/A Category:


Our 9×7 3-Part Bundles include Clear Acrylic Faces & Film Sheets with Yellow Wet Reflective. No matter which bundle size you choose, it’s matched components are covered by our BSAU145e certification shown on our website. So we guarantee your number plates will be road legal, subject to correct use. And this size makes yellow motorcycle number plates.

  • Size: 9×7 or 229x178mm
  • Contents: 9x7inch Clear Acrylic, Clear Film and Wet Reflective.
  • Bundle Size: 20 or 50 Plates
  • Colour: Yellow Only
  • For: Motorcycle Number Plates
  • Discount: 10% Off Trade Rate*

As you know, you have to print and join our components together to make a number plate. Therefore ensure your system prints onto clear film before buying this matched bundle.

Note* Reduction applies to standard trade accounts only. Customers with discount rates get their pre-agreed discount.

Bundle Components

9x7in Clear Acrylic

naw003 - 9x7in Clear Acrylic
All our Clear Acrylic Faces are certified to make Tennants number plates. But only when laminated to specific plate media. Not only is it UV stable to resist discolouring, but it also comes with a easy peel covers.

9x7in Clear Film

lg103f - 9x7in Clear Film
Tennants Clear Film is designed for printed number plate production. For 3-Part Plates, you simply sandwich it between an acrylic face and wet reflective. Each film sheet is coated with a substrate for better toner bonding.

9x7in Wet Reflective – Yellow

nrw003y - Yellow 9x7in Wet Reflective
Oralite Number Plate Reflective is made for number plate production. For 3-Part Plates, you simply laminate it to the back of a printed film sheet. As well as being fade resistant, each sheet comes with an adhesive coating for easy assembly.

3-Part Number Plates

3-Part Construction

Make 3-Part number plates by printing onto Clear Film, then laminating it between an Acrylic Face and Wet Reflective.

For more information on standards and regulations, check out our main site and the number plates pages or knowledge base.

Combining Matched Components

Roller jigs are used for plate assembly

Make a number plate using our 3 step process.
1: Design 2: Print 3: Assemble
Build it in our software, then print it out and simply assemble the matched components together.

Assemble with a Jig & Roller

Whenever you make a printed number plate, we recommend using a jig and roller for a professional finish.

3-Part Plates
  • Place your printed Clear Film face up on the jig.
  • Fold back a few centimetres of the adhesive cover on a Acrylic Face.
  • Position the Acrylic above the Film, Adhesive Side Down and carefully join the two pieces together
  • Leading with the joined edge, keep hold of the Fold and slowly wind the arm & Feed the parts through the roller.
  • This will remove the adhesive cover and bond the two parts together.
  • Next, put a Wet Reflective adhesive face up on the jig, folding back part of its cover.
  • Position the parts joined earlier on top with the Film Facing Down, join them together at the exposed edge
  • Once again Feed them through the rollers, keeping hold of the folded adhesive cover.
  • This will remove the final adhesive cover and Bond all the parts together.

Additional information

Dimensions229 × 178 mm
Media Type

3-Part Plates, Matched Bundles

Product Brand

Tennants UK
