Oblong Reflective Bundles

Oblong Reflective Bundles

Oblong Reflective Bundles

£210.00

In stock

£210.00

Our Oblong Reflective Bundles include enough Clear Acrylic & Dry Reflective for 50 BSAU145e Number Plates.

Bundle: Pick a Bundle Colour.

SKU: N/A Category:
Clear

Description

Our Oblong Reflective Bundles come with Clear Acrylic & Dry Reflective Sheets in either white or yellow. This set of matched components is covered by our BSAU145e certification, shown on our website. So we guarantee your number plates made from it will be road legal, subject to correct use. And these 1-line plates are the standard number plate size.

  • Size: 520x111mm – Oblong
  • Contents: Clear Acrylic & Dry Reflective.
  • Bundle Size: 50 Number Plates
  • Colour Options: White & Yellow Dry Reflective
  • For: Standard Oblong Plates.
  • Discount: 10% Off Trade Rate*

As you know, you have to print and join our components together to make a number plate. Therefore ensure your system prints onto reflective sheets before buying this matched bundle.

Note* Reduction applies to standard trade accounts only. Customers with discount rates get their pre-agreed discount.

Bundle Components

50 x Oblong Clear Acrylic

nas001 Oblong Clear Acrylic Face
Oralite Number Plate Reflective is designed for printed number plate production. But only when laminated to specific number plate components. Every clear acrylic face is UV stable to resist discolouring and comes with a wet adhesive for easy assembly.

50 x Oblong Dry Reflective

nrd001y - Yellow Oblong Dry Reflective Sheet
Oralite Number Plate Reflective is designed for printed number plate production. For Reflective Number Plates, you simply print on and then laminate it to the back of an acrylic face. Each retro reflective sheet is fade resistant and coated to help prints bond to the surface.

Reflective Number Plates

Reflective & Acrylic Construction

Make a reflective number plate by laminating your Printed Dry Reflective underneath an Acrylic Face.

For more information on standards and regulations, check out our main site and the number plates pages or knowledge base.

Combining Matched Components

Jig combining reflective and acrylic

Make a number plate using our 3 step process.
1: Design 2: Print 3: Assemble
Build it in our software, then print it out and simply assemble the matched components together.

Assembly with a Jig & Roller

Whenever you make a printed number plate, we recommend using a jig and roller for a professional finish.

Reflective Plates
  • Use the pins and place your Reflective on the jig, positioned flat and square.
  • Fold back a few centimetres of the adhesive cover on an Acrylic face.
  • Line up the Acrylic on top, Adhesive facing down towards the reflective.
  • Carefully join the components together at the Exposed adhesive, ensure the edges match.
  • Slide both parts towards the rollers, Joined edge nearest.
  • Take and keep Hold of the folded adhesive cover.
  • Slowly Wind the arm so the components are fed through the roller.
  • The adhesive cover should be Removed while the roller bonds the parts together.
  • Finally, remove the other protective Cover from the Acrylic.

Additional information

Dimensions520 × 111 mm
Media Type

Reflective Plates, Matched Bundles

Product Brand

Tennants UK
